CL500 Contactless Car Wash Machine

CL500 is the latest generation of frequency conversion and energy saving car wash equipment launched by Cheerwash.

Chassis/hub rinsing
Walking on the rails
Colorful light
Enhanced washing in front and rear area
Remote mobile phone/intenet operation

Quantity:
Availability:





Inquire Add to Basket

Model:
CL500

Products

Product Description

Equipment Size

Technical Parameters

Machine Functions

Site Size & Car Wash Size

Site Size(mm):6800*3650*3000

Car Wash Size(mm):5600*2600*2000

Technical Parameters

Technical data sheet	CL500
Minimum Controlling Room Size	6 square meters
Thickness for Concrete Ground	More than 15 cm and should be flat
Water Pump Motor	GB 6 Motor 15KW/380V
Max Water Pressure	10 MPa
Air-drying Motor	4 sets of 5.5KW motors/380V
Standard Water Consumption	90-140L/ circle rinsing
Standard Power Consumption	0.5-1.2 kWh
Standard Chemical Liquid Consumption (Adjustable)	20 - 150ML
Washing Time (Adjustable)	3-8 minutes
Moving Body Walking Way	Walking on rails
Total Power	37KW
Power Requirement	3 phase 380V / Single phase220V/50 Hz (can be customized)

Machine Functions

The two nylon wheels on the car wash glide smoothly along a track beam, providing simple operation and stability. This design was one of the first used in contactless car washes, ensuring reliable performance.

Walking on rails
High-pressure chassis washing removes sand, mud, and road chemicals, preventing corrosion and damage. It cleans from various angles, protects the undercarriage, reduces mechanical issues, and maintains the vehicle’s appearance and value.

Chassis/hub rinsing
Colorful lights enhance the visual appeal of car washing, especially at night, attracting customers and improving their experience. They create various colors with foam and can be easily turned on or off, saving energy and allowing for customization.

Colorful light
The foam covers the car completely and clings to the surface, improving detergent contact and effectiveness. This lava foam, with special detergents, cleans more thoroughly and removes stubborn dirt and grease.

Lava
Pre-soak foam, designed for fully automatic car washes, effectively breaks down dirt. After being sprayed, the equipment pauses for about 30 seconds (adjustable) before activating high-pressure water for thorough cleaning.

Pre-soak foam
Germany TBT dryers, with a 100% aluminum shell and a heavy-duty 18.5 kW frequency converter, quickly remove moisture from vehicles after washing, preventing water spots. This efficient drying process saves users time on manual wiping, ensuring a clean, dry finish.

Air-drying system/High pressure air drying
